Thecus N4100 IP Storage Appliance
58
RAID 0
RAID 0 is best suited for applications that need high bandwidth but do not require a high level of data
security. The RAID 0 level provides the best performance of all the RAID levels, but it does not provide data
redundancy.
RAID 0 uses disk striping and breaking up data into blocks to write across all hard drives in the volume. The
system can then use multiple hard drives for faster read and write. The stripe size parameter that was set
when the RAID was created determines the size of each block. No parity calculations complicate the write
operation.
HDD 1
Segment One
Segment Five
Segment Nine
HDD 2
Segment Two
Segment Six
Segment Ten
HDD 3
Segment Three
Segment Seven
Segment Eleven
HDD 4
Segment Four
Segment Eight
Segment Twelve
