Thecus N5500 - Page 121

To Next Page

To Previous Page

NOTE

1. With RAID volume encryption enabled, the system performance will

go down.

2. With RAID volume encryption enabled, RAID volume expansion will

operate in off line mode.

RAID volumes with encryption enabled will be displayed with a key lock symbol next

to volume ID name.

121
