Rear Panel
The N5500 rear panel features ports and connectors.
4
Back Panel
Item Description
1.WAN Port WAN port for connecting to an Ethernet network through a switch
or router
2.LAN Port LAN port for connecting to an Ethernet network through a switch
or router
3.Serial Port This port is for external UPS device
4.eSATA Port eSATA port for high-speed storage expansion
5.USB Port USB 2.0 port for compatible USB devices, such as USB disks, and
USB printers
6.System Fan System fan that exhausts heat from the unit
7.Power Connector Connect the included power cords to these connectors
8.USB Port USB 2.0 port to connect PC (Type B of target mode)
7
6
2
3
1
5
8
14

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Thecus N5500 and is the answer not in the manual?

Thecus N5500 Specifications

General IconGeneral
RAID levels0, 1, 5, 6, 10, JBOD
Storage drive size3.5 \
Hot-swap drive baysYes
Storage drive capacity- GB
Supported file systemsEXT3, XFS, ZFS
Storage drive interfaceSerial ATA
Total installed storage capacity0 TB
Maximum supported storage capacity10 TB
Number of storage drives installed0
Number of storage drives supported5
Flash memory128 MB
Internal memory1 GB
Internal memory typeDDR2
Processor frequency1.86 GHz
Supported network protocolsTCP/IP, CIFS/SMB, AFP, NFS, HTTP, HTTPS, FTP, FTP-SSL/TLS
USB 2.0 ports quantity6
Ethernet LAN (RJ-45) ports2
Dimensions (WxDxH)190 x 240 x 230 mm
Management platformLinux
Compatible operating systemsWindows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9 / X
Operating temperature (T-T)5 - 40 °C
Operating relative humidity (H-H)0 - 80 %
Power supply unit (PSU) capacity200 W
Weight and Dimensions IconWeight and Dimensions
Weight7200 g
