Thecus N5500 User Manual

Storage Management
The Storage menu displays the status of storage devices installed in the N5500,
and includes storage configuration options such as RAID and disk settings, folder
configuration, space allocation and ISO Mount.
Disks Information
From the Storage menu, choose the Disks item and the Disks Information
screen appears. From here, you can see various items about installed SATA hard
disks. Blank lines indicate that a SATA hard disk is not currently installed in that
particular disk slot.
Disks Information
Item Description
Disk No. Indicates disk location.
Capacity Shows the SATA hard disk capacity.
Model Displays the SATA hard disk model name.
Firmware Shows the SATA hard disk firmware version.
Status Indicates the status of the disk. Can read OK, Warning, or
Failed.
Bad Block scan Yes to start scan Bad Block.
Total Capacity Shows the total SATA hard disk capacity.
Disk Power
Management
The administrator can set the disk to power down after a period of
inactivity.
48

Thecus N5500 Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	- GB
Supported file systems	EXT3, XFS, ZFS
Storage drive interface	Serial ATA
Total installed storage capacity	0 TB
Maximum supported storage capacity	10 TB
Number of storage drives installed	0
Number of storage drives supported	5
Flash memory	128 MB
Internal memory	1 GB
Internal memory type	DDR2
Processor frequency	1.86 GHz
Supported network protocols	TCP/IP, CIFS/SMB, AFP, NFS, HTTP, HTTPS, FTP, FTP-SSL/TLS
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	2
Dimensions (WxDxH)	190 x 240 x 230 mm
Management platform	Linux
Compatible operating systems	Windows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9 / X
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Power supply unit (PSU) capacity	200 W

Weight and Dimensions

Weight	7200 g
