To use the Link Aggregation with “802.3ad selected” feature, please make sure
the networking equipment on the other end of Ethernet cable also supports
802.3ad protocol.
Enabling DHCP automatically turns on UPnP— see the Service Support Screen.
If you are only using the WAN port, we suggest that you disable IP Sharing
Mode. This will result in higher throughput.
A correct DNS setting is vital to networks services, such as SMTP and NTP.
Only use Jumbo Frame settings when operating in a Gigabit environment
where all other clients have Jumbo Frame Setting enabled.
NOTE
Most Fast Ethernet (10/100) Switches/Routers do not support Jumbo Frame and you will not
be able to connect to your N5500 after Jumbo Frame is turned on. If this happens, turn off the
N5500. Then, press the reset button on the front panel right below power button. System will
bring your network settings back to factory default.
WARNING
LAN
LAN Configuration
The N5500 supports two Gigabit Ethernet ports for higher service availability. To
configure these ports, choose LAN from the System Network menu, and the LAN
Configuration screen appears. Press Apply to save your changes.
LAN Configuration
Item Description
MAC Address Displays the MAC address of the LAN interface.
Jumbo Frame Support Enable or disable Jumbo Frame Support on the LAN interface.
IP Specifies the IP address of the LAN interface.
Netmask Specifies the Network Mask of the LAN interface.
Before enabling Jumbo Frame Support, please make sure your network equipment
supports Jumbo Frame. If your equipment is incompatible, you might not be able to
connect to your N5500.
NOTE
40

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Thecus N5500 and is the answer not in the manual?

Thecus N5500 Specifications

General IconGeneral
RAID levels0, 1, 5, 6, 10, JBOD
Storage drive size3.5 \
Hot-swap drive baysYes
Storage drive capacity- GB
Supported file systemsEXT3, XFS, ZFS
Storage drive interfaceSerial ATA
Total installed storage capacity0 TB
Maximum supported storage capacity10 TB
Number of storage drives installed0
Number of storage drives supported5
Flash memory128 MB
Internal memory1 GB
Internal memory typeDDR2
Processor frequency1.86 GHz
Supported network protocolsTCP/IP, CIFS/SMB, AFP, NFS, HTTP, HTTPS, FTP, FTP-SSL/TLS
USB 2.0 ports quantity6
Ethernet LAN (RJ-45) ports2
Dimensions (WxDxH)190 x 240 x 230 mm
Management platformLinux
Compatible operating systemsWindows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9 / X
Operating temperature (T-T)5 - 40 °C
Operating relative humidity (H-H)0 - 80 %
Power supply unit (PSU) capacity200 W
Weight and Dimensions IconWeight and Dimensions
Weight7200 g
