Thecus N5500 User Manual

IO Mapping There are three selections available:
• Guest system root account will have full access to this
share (root:root).
• Guest system root account will be mapped to anonymous
user (nobody:nogroup) on NAS.
• All user on guest system will be mapped to anonymous
user (nobody:nogroup) on NAS.
Choose the one which best fits your needs.
Apply Click to save your changes.
Snapshot
The N5500 is capable for 16 snapshot version control. To have snapshot to work on,
the file system creation for RAID volume has to be “ZFS”.
Snap (Snapshot configuration)
If added folder has located in the RAID volume with “ZFS” file system, then the
folder management screen with “Snap” button will be configurable.
Snapshot
Item Description
Take Shot Click to take snapshot right away.
Remove Click to remove snapshot schedule.
Schedule Click to open snapshot schedule setup screen.
Clicking on schedule button then schedule setup screen appear. Checked the enable
check box to activate the snapshot scheduled operation.
68

Thecus N5500 Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	- GB
Supported file systems	EXT3, XFS, ZFS
Storage drive interface	Serial ATA
Total installed storage capacity	0 TB
Maximum supported storage capacity	10 TB
Number of storage drives installed	0
Number of storage drives supported	5
Flash memory	128 MB
Internal memory	1 GB
Internal memory type	DDR2
Processor frequency	1.86 GHz
Supported network protocols	TCP/IP, CIFS/SMB, AFP, NFS, HTTP, HTTPS, FTP, FTP-SSL/TLS
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	2
Dimensions (WxDxH)	190 x 240 x 230 mm
Management platform	Linux
Compatible operating systems	Windows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9 / X
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Power supply unit (PSU) capacity	200 W

Weight and Dimensions

Weight	7200 g
