Chapter 4: System Administration
Overview
The N5500 provides an easily accessible Web Administration Interface. With it,
you can configure and monitor the N5500 anywhere on the network.
Web Administration Interface
Make sure your network is connected to the Internet. To access the N5500 Web
Administration Interface:
1. Type the N5500’s IP address into your browser. (Default IP address is
http://192.168.1.100)
NOTE
Your computer’s network IP address must be on the same subnet as the N5500.
If the N5500 has default IP address of 192.168.1.100, your managing PC IP
address must be 192.168.1.x, where x is a number between 1 and 254, but not
100.
2. Login to the system using the administrator user name and password. The
factory defaults are:
User Name: admin
Password: admin
※ If you changed your password in the setup wizard, use the new password.
Once you are logged in as an administrator, you will see the Web Administration
Interface. From here, you can configure and monitor virtually every aspect of the
N5500 from anywhere on the network.
Menu Bar
The Menu Bar is where you will find all of the information screens and system
settings of the N5500. The various settings are placed in the following groups on the
menu bar:
24
