Thermal Dynamics CUTMASTER 102 Service Manual

cutmaster 102
Manual 0-4998 5-31 SERVICE
LOGIC PCB 3 SIGNALS
J1 Signal info is the same as MAIN PCB 1 J2 connector.
jJ3-1 +5VDC
j3-2 Pressure Transducer output 0.5 to 5 VDC / 0 - 100 psi
J3-3 Common
LOGIC PCB 3 LED INDICATORS
NORMAL INDICATION FIRMWARE VERSION ERROR MESSAGE
D1 +12VDC
D2 MAX PRESSURE X.7 Over Pressure
D3 90 PSI X.6 Internal Error
D4 85 PSI X.5 Shorted torch (Output Fault)
D5 80 PSI X.4 Tip Missing
D6 75 PSI X.3 Start Signal active during power up
D7 70 PSI X.2 Parts-In-Place Fault (PIP)
D8 65 PSI X.1 Input Power Fault
D9 MIN PRESSURE X.0 Low Pressure
D10 AC 1.X
D11 OVERTEMP 2.X
D12 GAS 3.X
D13 DC 4.X
D14 ERROR 5.X
LOGIC PCB 3 TEST POINTS
TP1 Common
TP2 +12VDC
TP3 +5VDC
TP4 +3.3DCV
TP5 0.5 to 5 VDC / 0 - 100 psi
TP6 +1.8VDC
TP7 Potentiometer Current Demand (0-3.3VDC)

Thermal Dynamics CUTMASTER 102 Specifications

General

Brand	Thermal Dynamics
Model	CUTMASTER 102
Category	Welding System
Language	English
