cutmaster 102
Manual 0-4998 2-3 INTRODUCTION
2.05 Input Wiring Specifications
CutMaster 102 Power Supply Input Cable Wiring Requirements
Input voltage Freq Power Input Suggested Sizes
Volts Hz kVA I max I eff Fuse (amps)
Flexible Cord
(AWG)
1 Phase
208 60 19 90 80 100 2
230 60 20 85 78 100 2
460 60 27 57 50 60 4
3 Phase
208 60 19 52 45 60 6
230 60 18 45 43 60 6
460 60 22 27 24 40 10
230 50 14 34 22 40 12
400 50 19 27 17 30 12
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electric Code
NOTES
Refer to Local and National Codes or local authority having jurisdiction for proper wiring requirements.
The suggested sizes are based on flexible power cable with power plug installations. For hard-wired installations
refer to local or national codes.
I
1
max is taken at TDC rated minimum duty cycle.
I
1
eff is taken at TDC 100% rated duty cycle.
