Thermal Dynamics CUTMASTER 60i Operating Manual

CUTMASTER 60i
OPERATION Manual 0-5436
4T-10
CutMaster® 60i With Exposed Tip Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per
Minute)
Standoff Plasma Gas
Pressure*
Flow (SCFH) Pierce Pierce
Height
Inches mm (Cat.
No.)
Volts
(VDC)
(Amps) Inches Meters Inches mm psi bar Plasma Total** Delay
(Sec)
Inches mm
0.032 0.8 9-8208 110 40 440 11.18 0.187 4.8
Set to the
central
region on
the pressure
dial. This is
illuminated
green when
selected.
55 170 0.00 0.2 5.1
0.051 1.3 9-8208 109 40 350 8.89 0.187 4.8 55 170 0.10 0.2 5.1
0.064 1.6 9-8208 112 40 250 6.35 0.187 4.8 55 170 0.10 0.2 5.1
0.079 2.0 9-8208 112 40 200 5.08 0.19 4.8 55 170 0.30 0.2 5.1
0.125 3.2 9-8208 118 40 100 2.54 0.19 4.8 55 170 0.40 0.2 5.1
0.188 4.8 9-8208 120 40 98 2.49 0.187 4.8 55 170 0.60 0.2 5.1
0.250 6.4 9-8208 123 40 50 1.27 0.187 4.8 55 170 1.00 0.2 5.1
0.375 9.5 9-8208 134 40 16 0.41 0.187 4.8 55 170 NR NR NR
CutMaster® 60i With Exposed Tip Type Material: Mild Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per
Minute)
Standoff Plasma Gas
Pressure*
Flow (SCFH) Pierce Pierce Height
Inches mm (Cat.
No.)
Volts
(VDC)
(Amps) Inches Meters Inches mm psi bar Plasma Total** Delay
(Sec)
Inches mm
0.060 1.5 9-8210 110 60 290 7.37 0.19 4.8
Set to the
central
region on
the pressure
dial. This is
illuminated
green when
selected.
90 245 0.00 0.19 4.8
0.075 1.9 9-8210 120 60 285 7.24 0.19 4.8 90 245 0.10 0.19 4.8
0.120 3.0 9-8210 120 60 180 4.57 0.19 4.8 90 245 0.10 0.19 4.8
0.135 3.4 9-8210 119 60 170 4.32 0.19 4.8 90 245 0.10 0.19 4.8
0.188 4.8 9-8210 121 60 100 2.54 0.19 4.8 90 245 0.20 0.19 4.8
0.250 6.4 9-8210 119 60 80 2.03 0.19 4.8 90 245 0.30 0.19 4.8
0.375 9.5 9-8210 124 60 50 1.27 0.19 4.8 90 245 0.50 0.19 4.8
0.500 12.7 9-8210 126 60 26 0.66 0.19 4.8 90 245 0.75 0.19 4.8
0.625 15.9 9-8210 127 60 19 0.48 0.19 4.8 90 245 Rolling Pierce
0.750 19.1 9-8210 134 60 14 0.36 0.19 4.8 90 245 Rolling Pierce
1.000 25.4 9-8210 140 60 6 0.15 0.19 4.8 90 245 Rolling Pierce
1.250 31.8 9-8210 NR, manual cutting only 90 245 NR
1.500 38.1 9-8210 NR, manual cutting only 90 245 NR
