Thermal Dynamics CUTMASTER 60i Operating Manual

CUTMASTER 60i
OPERATION Manual 0-5436
4T-12
4T.09 Recommended Cutting Speeds With Shielded Tip
CutMaster® 60i With Shielded Tip Type Material: Mild Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per
Minute)
Standoff Plasma Gas
Pressure*
Flow (SCFH) Pierce Pierce
Height
Inches mm (Cat.
No.)
Volts
(VDC)
(Amps) Inches Meters Inches mm psi bar Plasma Total** Delay
(Sec)
Inches mm
0.036 0.9 9-8208 114 40 170 4.32 0.19 4.8
Set to the
central
region on
the pressure
dial. This is
illuminated
green when
selected.
55 170 0.00 0.2 5.1
0.06 1.5 9-8208 120 40 90 2.29 0.19 4.8 55 170 0.10 0.2 5.1
0.075 1.9 9-8208 121 40 80 2.03 0.19 4.8 55 170 0.30 0.2 5.1
0.135 3.4 9-8208 122 40 75 1.91 0.19 4.8 55 170 0.40 0.2 5.1
0.188 4.8 9-8208 123 40 30 0.76 0.19 4.8 55 170 0.60 0.2 5.1
0.25 6.4 9-8208 125 40 25 0.64 0.19 4.8 55 170 1.00 0.2 5.1
0.375 9.5 9-8208 138 40 11 0.28 0.19 4.8 55 170 NR NR NR
0.500 12.7 9-8208 142 40 7 0.18 0.19 4.8 55 170 NR NR NR
0.625 15.9 9-8208 152 40 3 0.08 0.19 4.8 55 170 NR NR NR
CutMaster® 60i With Shielded Tip Type Material: Stainless Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per
Minute)
Standoff Plasma Gas
Pressure*
Flow (SCFH) Pierce Pierce
Height
Inches mm (Cat.
No.)
Volts
(VDC)
(Amps) Inches Meters Inches mm psi bar Plasma Total** Delay
(Sec)
Inches mm
0.036 0.9 9-8208 109 40 180 4.57 0.125 3.2
Set to the
central
region on
the pressure
dial. This is
illuminated
green when
selected.
55 170 0.00 0.2 5.1
0.05 1.3 9-8208 105 40 165 4.19 0.125 3.2 55 170 0.00 0.2 5.1
0.06 1.5 9-8208 115 40 120 3.05 0.125 3.2 55 170 0.10 0.2 5.1
0.078 2.0 9-8208 120 40 65 1.65 0.187 4.8 55 170 0.30 0.2 5.1
0.135 3.4 9-8208 125 40 25 0.64 0.187 4.8 55 170 0.40 0.2 5.1
0.188 4.8 9-8208 132 40 20 0.51 0.187 4.8 55 170 0.60 0.2 5.1
0.25 6.4 9-8208 130 40 15 0.38 0.187 4.8 55 170 1.00 0.2 5.1
0.375 9.5 9-8208 130 40 10 0.25 0.187 4.8 55 170 NR NR NR
CutMaster® 60i With Shielded Tip Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per
Minute)
Standoff Plasma Gas
Pressure*
Flow (SCFH) Pierce Pierce
Height
Inches mm (Cat.
No.)
Volts
(VDC)
(Amps) Inches Meters Inches mm psi bar Plasma Total** Delay
(Sec)
Inches mm
0.032 0.8 9-8208 116 40 220 5.59 0.187 4.8 Set to the
central
region on
the pressure
dial. This is
illuminated
green when
selected.
55 170 0.00 0.2 5.1
0.051 1.3 9-8208 116 40 210 5.33 0.187 4.8 55 170 0.00 0.2 5.1
0.064 1.6 9-8208 118 40 180 4.57 0.187 4.8 55 170 0.10 0.2 5.1
0.079 2.0 9-8208 116 40 150 3.81 0.19 4.8 55 170 0.30 0.2 5.1
0.125 3.2 9-8208 130 40 75 1.91 0.19 4.8 55 170 0.40 0.2 5.1
0.188 4.8 9-8208 132 40 60 1.52 0.187 4.8 55 170 0.60 0.2 5.1
0.250 6.4 9-8208 134 40 28 0.71 0.187 4.8 55 170 1.00 0.2 5.1
0.375 9.5 9-8208 143 40 11 0.28 0.187 4.8 55 170 NR NR NR
