PARTS LISTS 6-4 Manual 0-2962
6.04 Replacement Parts - for Machine Torches with Unshielded Leads
Item No. Qty Description Catalog No.
1 1 Torch Head Assembly without leads (includes items 2, 3, and 14) 9-8220
2 1 Large O - Ring 8-3487
3 1 Small O - Ring 8-3486
4 1 PIP Switch Kit 9-7036
5 Unshielded Mechanized Leads Assemblies with O2B connectors
1 25 - foot / 7.6 m Leads Assembly with O2B connectors 4-7838*
1 50 - foot / 15.2 m Leads Assembly with O2B connectors 4-7839*
6 Unshielded Automated Leads Assemblies with ATC connectors
1 5 - foot / 1.5 m Leads Assembly with ATC connector 4-7850
1 10 - foot / 3.05 m Leads Assembly with ATC connector 4-7851
1 25 - foot / 7.6 m Leads Assembly with ATC connector 4-7852
1 50 - foot / 15.2 m Leads Assembly with ATC connector 4-7853
7 Unshielded Mechanized Leads Assemblies with ATC connectors
1 5 - foot / 1.5 m Leads Assembly with ATC connector 4-7842
1 10 - foot / 3.05 m Leads Assembly with ATC connector 4-7843
1 25 - foot / 7.6 m Leads Assembly with ATC connector 4-7844
1 50 - foot / 15.2 m Leads Assembly with ATC connector 4-7845
8 1 11" / 279 mm Rack 9-7041
9 1 11" / 279 mm Mounting Tube 9-7043
10 1 End Cap Assembly 9-7044
11 2 Body, Mounting, Pinch Block 9-4513
12 1 Pin, Mounting, Pinch Block 9-4521
13 1 Torch Holder Sleeve 7-2896
14 1 PIP Plunger and Return Spring Kit 9-7045
15 1 Torch Control Cable Adapter for Unshielded Leads (includes item # 16) 7-3447
16 1 Through - Hole Protector 9-8103
1 Pinion Assembly (Not shown) 7-2827
1 5" / 126 mm Positioning Tube (Not shown) 9-7042
NOTE
* Does not include Control Cable Adapter or Through - Hole
Protector.
Refer to Section 6.05 for Replacement Shielded Leads Assemblies.
