Thermal Dynamics SL100 HAND TORCH User Manual

PARTS LISTS 6-8 Manual 0-2962
6.06 Hand Torch Consumables
The illustration shows all consumable parts for the
SL60 and SL100 hand torches. Refer to the Appendix
pages covering the power supply being used to ensure
proper selection for the application.
Various front - end torch parts are available for different
applications.
Use the single - piece shield cup for general purpose cut-
ting operations with the torch tip in contact with the work
(up to 40 amps). This is the preferred method of cutting
sheet metal up to 3/16" or 4.8 mm thick.
Also use the single - piece Shield Cup for 'standoff' cutting
(with the torch tip 1/8" to 1/4" from the workpiece). This is the
preferred method for cutting metal thicker than 3/16" / 4.8 mm
and at current levels above 40 amps. This provides maximum
visibility and accessibility.
The Standoff Guide fits Shield Cup No. 9-8218 and en-
ables the user to maintain a consistent standoff height for
most applications.
Use the Shield Cup Body with the Deflector Shield Cap
for extended parts life and improved resistance to reflected
heat. This combination provides cutting results similar
to the single-piece Shield Cup, as well as easy change-
over to gouging or drag shield cutting.
Use the Shield Cup Body with the Drag Shield Cap for a con-
sistent standoff distance with the drag shield in contact with
the workpiece. This is a simple and operator-friendly method
of cutting between 50 and 100 amps.
Use the Shield Cup Body with the Gouging Shield Cap for
excellent gouging performance and enhanced torch parts life.
The electrode and starter cartridge are the same for all opera-
tions.
6.07 Hand Torch Spare Parts Kits
Item
Catalog No.
40-Amp Kit,
Cat No.
5-0050
60-Amp Kit,
Cat No.
5-0075
80-Amp Kit,
Cat No.
5-0110
100-Amp Kit,
Cat No.
5-0170
Electrode 9-8215 3 3 3 3
40A Drag Tip 9-8207 5 2 2 2
40A Standoff Tip 9-8208 2
60A Standoff Tip 9-8210 5
80A Standoff Tip 9-8211 5
100A Standoff Tip 9-8212 5
Shield Cup Body 9-8237 1 1 1
Drag Shield Cap, 50-60A 9-8235 1
Drag Shield Cap, 70-100A 9-8236 1 1
Large O-Ring 8-3487 1 1 1 1
Small O-Ring 8-3486 1 1 1 1
Standoff Guide 9-8251 1
Standoff Guide 9-8281 1 1 1
Hand Torch Spare Parts Kit Contents
