PARTS LISTS 6-10 Manual 0-2962
6.08 Machine Torch Consumables
The illustration shows all consumable parts for the
SL100 machine torches. Refer to the Appendix pages
covering the power supply being used to ensure proper
selection for the application.
Various front - end torch parts are available for different
applications.
Use the single - piece Shield Cup for 'standoff' cutting (with the
torch tip 1/8" to 1/4" from the workpiece). This is the preferred
method for cutting metal thicker than 3/16" / 4.8 mm and at
current levels above 40 amps. This provides maximum visibility
and accessibility.
Use the Shield Cup Body with the Deflector Shield Cap for
extended parts life and improved resistance to reflected heat.
This combination provides cutting results similar to the single-
piece Shield Cup, as well as easy change-over to gouging or
drag shield cutting.
Use the Shield Cup Body with the Gouging Shield Cap for ex-
cellent gouging performance and enhanced torch parts life.
The electrode and starter cartridge are the same for all opera-
tions.
6.09 Machine Torch Spare Parts Kits
Item
Catalog No.
40-Amp Kit,
Cat No.
5-0052
60-Amp Kit,
Cat No.
5-0077
80-Amp Kit,
Cat No.
5-0120
100-Amp Kit,
Cat No.
5-0171
Electrode 9-8215 3 3 3 3
40A Standoff Tip 9-8208 5 5 5 5
60A Standoff Tip 9-8210 5
80A Standoff Tip 9-8211 5
100A Standoff Tip 9-8212 5
Shield Cup 9-82181111
Large O-Ring 8-3487 1 1 1 1
Small O-Ring 8-3486 1 1 1 1
Start Cartridge 9-8213 1 1 1 1
Machine Torch Spare Parts Kit Contents
