6.10 Automated Torch Consumables
The illustration shows all consumable parts for the
SL100 automated torch. Refer to the Appendix pages
covering the power supply being used to ensure
proper selection for the application.
Various front - end torch parts are available for different ap-
plications.
The Shield Cup Body with the Deflector Shield Cap pro-
vides extended parts life and improved resistance to
reflected heat. This combination provides easy change-
over to gouging or drag shield cutting.
Use the Shield Cup Body with the Gouging Shield Cap for
excellent gouging performance and enhanced torch parts
life.
The electrode and starter cartridge are the same for all opera-
tions.
6.11 Automated Torch Spare Parts Kits
Item
Catalog No.
40-Amp Kit,
Cat No.
5-0054
60-Amp Kit,
Cat No.
5-0079
80-Amp Kit,
Cat No.
5-0122
100-Amp Kit,
Cat No.
5-0174
Electrode 9-8215 3 3 3 3
30A Standoff Tip 9-8206 5 5 5 5
40A Standoff Tip 9-8208 5 5 5 5
60A Standoff Tip 9-8210 5 5 5
80A Standoff Tip 9-8211 5 5
100A Standoff Tip 9-8212 5
Shield Cup Body 9-8237 1 1 1 1
Shield Cap, Deflector 9-8243 1 1 1 1
Shield Cap, Machine, 40A 9-8245 1 1 1 1
Shield Cap, Machine, 60A 9-8238 1 1 1
Shield Cap, Machine, 70-100A 9-8239 1 1
Large O-Ring 8-3487 1 1 1 1
Small O-Ring 8-3486 1 1 1 1
Start Cartridge 9-8213 1 1 1 1
Ohmic Clip Kit 9-8224 1 1 1 1
Automation Torch Spare Parts Kit Contents
