Thermal Dynamics SL100 HAND TORCH User Manual

Manual 0-2962 A-15 APPENDIX
Air Plasma Cutting Speed Data Chart For CutMaster 151
Type Torch: SL100 Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Volts Amperage Speed (Per Minute) Plasma Gas Press Flow (SCFH) Pierce Pierce Height
Inches
mm
(Cat. No.) (VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
1/4 6.4 9-8212 104 100 148 3.76 0.19 4.8 70 4.8 90 490 0 0.19 4.8
3/8 9.5 9-8212 110 100 118 3.00 0.19 4.8 70 4.8 90 490 0 0.19 4.8
1/2 12.7 9-8212 113 100 79 2.01 0.19 4.8 70 4.8 90 490 0 0.19 4.8
3/4 19.1 9-8212 118 100 31 0.79 0.19 4.8 70 4.8 90 490 0 0.19 4.8
1 25.4 9-8212 121 100 18 0.46 0.19 4.8 70 4.8 90 490 NR 0.19 4.8
1-1/4 31.8 9-8212 128 100 14 0.36 0.19 4.8 70 4.8 90 490 NR 0.19 4.8
1-1/2 38.1 9-8212 133 100 11 0.28 0.19 4.8 70 4.8 90 490 NR 0.19 4.8
Standoff
Air Plasma Cutting Speed Data Chart For CutMaster 151
Type Torch: SL100 Type Material: Mild Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Volts Amperage
S
peed (Per Minute
)
Standoff Plasma Gas Pres
s
Flow (SCFH) Pierce Pierce Height
Inches
mm
(Cat. No.) (VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
1/4 6.4 9-8212 104 100 129 3.28 0.19 4.8 70 4.8 90 490 0 0.19 4.8
3/8 9.5 9-8212 110 100 65 1.65 0.19 4.8 70 4.8 90 490 0 0.19 4.8
1/2 12.7 9-8212 113 100 49 1.24 0.19 4.8 70 4.8 90 490 0 0.19 4.8
3/4 19.1 9-8212 118 100 24 0.61 0.19 4.8 70 4.8 90 490 0 0.19 4.8
1 25.4 9-8212 121 100 16 0.41 0.19 4.8 70 4.8 90 490 NR 0.19 4.8
1-1/4 31.8 9-8212 128 100 10 0.25 0.19 4.8 70 4.8 90 490 NR 0.19 4.8
1-1/5 38.1 9-8212 133 100 8 0.20 0.19 4.8 70 4.8 90 490 NR 0.19 4.8
Air Plasma Cutting Speed Data Chart For CutMaster 151
Type Torch: SL100 Type Material: Stainless Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Volts Amperage
S
peed (Per Minute
)
Standoff Plasm a Gas Pres
s
Flow (SCFH) Pie rce Pier ce He ight
Inches
mm
(Cat. No.) (VDC)
(Amps)
Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
1/4 6.4 9-8212 104 100 134 3.40 0.19 4.8 70 4.8 90 490 0 0.19 4.8
3/8 9.5 9-8212 110 100 67 1.70 0.19 4.8 70 4.8 90 490 0 0.19 4.8
1/2 12.7 9-8212 113 100 40 1.02 0.19 4.8 70 4.8 90 490 0 0.19 4.8
3/4 19.1 9-8212 118 100 22 0.56 0.19 4.8 70 4.8 90 490 0 0.19 4.8
1 25.4 9-8212 123 100 12 0.30 0.19 4.8 70 4.8 90 490 NR 0.19 4.8
1-1/4 31.8 9-8212 129 100 9 0.23 0.19 4.8 70 4.8 90 490 NR 0.19 4.8
1-1/2 38.1 9-8212 135 100 6 0.15 0.19 4.8 70 4.8 90 490 NR 0.19 4.8
Cutting Speed Charts
NOTES
* Gas pressure shown is for torches with leads up to 25' / 7.6 m long. For 50' / 15.2 m leads, set gas pressure to 75
psi / 5.2 bar.
** Total flow rate includes plasma and secondary gas flow.
