Thermal Dynamics SL100 HAND TORCH User Manual

Manual 0-2962 A-21 APPENDIX
Air Plasma Cutting Speed Data Chart For PakMaster 75XL Plus
Type Torch: SL60 Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Volts Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (SCFH) Pierce Pierce Height
Inches
mm
(Cat. No.) (VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
1/16 1.6 9-8210 95 60 350 8.89 0.19 4.8 65 4.5 80 350 0.1 0.25 6.4
1/8 3.2 9-8210 95 60 175 4.45 0.19 4.8 65 4.5 80 350 0.25 0.25 6.4
1/4 6.4 9-8210 105 60 80 2.03 0.19 4.8 65 4.5 80 350 0.25 0.25 6.4
3/8 9.5 9-8210 105 60 45 1.14 0.19 4.8 65 4.5 80 350 0.25 0.25 6.4
1/2 12.7 9-8210 105 60 22 0.56 0.19 4.8 65 4.5 80 350 0.5 0.25 6.4
3/4 19.1 9-8210 115 60 12 0.30 0.19 4.8 65 4.5 80 350 NA NA NA
Air Plasma Cutting Speed Data Chart For PakMaster 75XL Plus
Type Torch: SL60 Type Material: Mild Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Volts Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (SCFH) Pierce Pierce Height
Inches
mm
(Cat. No.) (VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
1/16 1.6 9-8210 90 60 350 8.89 0.19 4.8 65 4.5 80 350 0.1 0.25 6.4
1/8 3.2 9-8210 95 60 175 4.45 0.19 4.8 65 4.5 80 350 0.25 0.25 6.4
1/4 6.4 9-8210 105 60 80 2.03 0.19 4.8 65 4.5 80 350 0.25 0.25 6.4
3/8 9.5 9-8210 105 60 45 1.14 0.19 4.8 65 4.5 80 350 0.25 0.25 6.4
1/2 12.7 9-8210 105 60 22 0.56 0.19 4.8 65 4.5 80 350 0.5 0.25 6.4
3/4 19.1 9-8210 115 60 11 0.28 0.19 4.8 65 4.5 80 350 NA NA NA
1 25.4 9-8210 115 60 8 0.20 0.19 4.8 65 4.5 80 350 NA NA NA
Air Plasma Cutting Speed Data Chart For PakMaster 75XL Plus
Type Torch: SL60 Type Material: Stainless Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Volts Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (SCFH) Pierce Pierce Height
Inches
mm
(Cat. No.) (VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
1/16 1.6 9-8210 95 60 350 8.89 0.19 4.8 65 4.5 80 350 0.1 0.25 6.4
1/8 3.2 9-8210 95 60 150 3.81 0.19 4.8 65 4.5 80 350 0.25 0.25 6.4
1/4 6.4 9-8210 105 60 70 1.78 0.19 4.8 65 4.5 80 350 0.25 0.25 6.4
3/8 9.5 9-8210 105 60 35 0.89 0.19 4.8 65 4.5 80 350 0.25 0.25 6.4
1/2 12.7 9-8210 105 60 20 0.51 0.19 4.8 65 4.5 80 350 0.5 0.25 6.4
3/4 19.1 9-8210 115 60 10 0.25 0.19 4.8 65 4.5 80 350 NA NA NA
Cutting Speed Charts
NOTES
* Gas pressure shown is for torches with leads up to 25' / 7.6 m long. For 50' / 15.2 m leads, set gas pressure to 75 psi
/ 5.2 bar.
** Total flow rate includes plasma and secondary gas flow.
