Thermal Dynamics SL100 HAND TORCH User Manual

Manual 0-2962 A-25 APPENDIX
Air Plasma Cutting Speed Data Chart For PakMaster 100XL Plus
Type Torch: SL100 Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Volts Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (SCFH) Pierce Pierce Height
Inches
mm
(Cat. No.) (VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0.05 1.3 9-8211 100 80 350 8.89 0.19 4.8 60 4.1 90 490 0 0.19 4.8
0.125 3.2 9-8211 103 80 225 5.72 0.19 4.8 60 4.1 90 490 0 0.19 4.8
1/4 6.4 9-8211 106 80 112 2.84 0.19 4.8 60 4.1 90 490 0 0.19 4.8
3/8 9.5 9-8211 111 80 55 1.40 0.19 4.8 60 4.1 90 490 0 0.19 4.8
1/2 12.7 9-8211 115 80 30 0.76 0.19 4.8 60 4.1 90 490 0 0.19 4.8
3/4 19.1 9-8211 117 80 10 0.25 0.19 4.8 60 4.1 90 490 NR 0.19 4.8
1 25.4 9-8211 120 80 8 0.20 0.19 4.8 60 4.1 90 490 NR 0.19 4.8
Air Plasma Cutting Speed Data Chart For PakMaster 100XL Plus
Type Torch: SL100 Type Material: Mild Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Volts Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (SCFH) Pierce Pierce Height
Inches
mm
(Cat. No.) (VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
1/16 1.6 9-8211 100 80 350 8.89 0.19 4.8 60 4.1 90 490 0 0.20 5.1
1/8 3.2 9-8211 103 80 230 5.84 0.19 4.8 60 4.1 90 490 0.1 0.20 5.1
1/4 6.4 9-8211 106 80 112 2.84 0.19 4.8 60 4.1 90 490 0.1 0.20 5.1
3/8 9.5 9-8211 111 80 55 1.40 0.19 4.8 60 4.1 90 490 0.1 0.20 5.1
1/2 12.7 9-8211 112 80 38 0.97 0.19 4.8 60 4.1 90 490 0.1 0.20 5.1
3/4 19.1 9-8211 117 80 18 0.46 0.19 4.8 60 4.1 90 490 NA NA NA
1 25.4 9-8211 120 80 10 0.25 0.19 4.8 60 4.1 90 490 NA NA NA
Air Plasma Cutting Speed Data Chart For PakMaster 100XL Plus
Type Torch: SL100 Type Material: Stainless Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Volts Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (SCFH) Pierce Pierce Height
Inches
mm
(Cat. No.) (VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0.05 1.3 9-8211 100 80 350 8.89 0.19 4.8 60 4.1 90 490 0 0.19 4.8
0.125 3.2 9-8211 103 80 200 5.08 0.19 4.8 60 4.1 90 490 0 0.19 4.8
1/4 6.4 9-8211 106 80 112 2.84 0.19 4.8 60 4.1 90 490 0.25 0.19 4.8
3/8 9.5 9-8211 111 80 55 1.40 0.19 4.8 60 4.1 90 490 0.25 0.19 4.8
1/2 12.7 9-8211 112 80 38 0.97 0.19 4.8 60 4.1 90 490 0.25 0.19 4.8
3/4 19.1 9-8211 117 80 18 0.46 0.19 4.8 60 4.1 90 490 NR 0.19 4.8
1 25.4 9-8211 120 80 10 0.25 0.19 4.8 60 4.1 90 490 NR 0.19 4.8
Cutting Speed Charts
NOTES
* Gas pressure shown is for torches with leads up to 25' / 7.6 m long. For 50' / 15.2 m leads, set gas pressure to 65 psi
/ 4.5 bar.
** Total flow rate includes plasma and secondary gas flow.
