ThinkPad Edge E530 - LCD Unit Replacement

StepScrew(quantity)Color
Torque
3
M2×5mm,wafer-head,nylon-coated(1)Silver
0.181Nm
(1.85kgf-cm)
1210LCDunit
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
•“1030Smallbottomcover”onpage64
•“1040Opticaldriveorblankbezel”onpage65
•“1070PCIExpressMiniCardforwirelessLAN”onpage68
•“1080PCIExpressMiniCardforwirelessWANormSATAsolidstatedrive”onpage69
•“1120Keyboard”onpage76
•“1130Keyboardbezel”onpage80
•“1190RJ45subcard”onpage91
RemovalstepsofLCDunit
2
2
2
2
1
Wheninstalling:Makesurethattheconnectorisattachedrmlytothesystemboard.
StepScrew(quantity)Color
Torque
2
M2.5×5mm,wafer-head,nylon-coated(4)
Black0.392Nm
(4kgf-cm)
94HardwareMaintenanceManual
