ThinkPad Edge E530 - 1100 Thermal Fan; 1110 Thermal Pipes

1100Thermalfan
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
Removalstepsofthermalfan
Note:Loosenthescrews2.
1
2
2
2
Note:Yourmodelmightlookslightlydifferentfromtheillustrationabove.
Wheninstalling:Makesurethattheconnectorisattachedrmlytothesystemboard.
3
Note:Yourmodelmightlookslightlydifferentfromtheillustrationabove.
Wheninstalling:Donotpressthetopofthefancoverandthefanhub.
1110Thermalpipes
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
74HardwareMaintenanceManual
