ThinkPad Edge E530 - 1220 Base Cover Assembly and DC-In Connector

1220BasecoverassemblyandDC-inconnector
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
•“1030Smallbottomcover”onpage64
•“1040Opticaldriveorblankbezel”onpage65
•“1060Harddiskdriveassembly”onpage66
•“1070PCIExpressMiniCardforwirelessLAN”onpage68
•“1080PCIExpressMiniCardforwirelessWANormSATAsolidstatedrive”onpage69
•“1090Backupbattery”onpage73
•“1100Thermalfan”onpage74
•“1110Thermalpipes”onpage74
•“1120Keyboard”onpage76
•“1130Keyboardbezel”onpage80
•“1150Systemboardassembly”onpage83
•“1160Speakerassembly”onpage86
•“1170Powerbuttonsubcard”onpage89
•“1180I/OsubcardwithUSBconnectorandaudiojack”onpage90
•“1190RJ45subcard”onpage91
•“1200Opticaldrivesubcard”onpage93
RemovalstepsofbasecoverassemblyandDC-inconnector
1
1
1
1
2
StepScrew(quantity)Color
Torque
1
M2.5×5mm,wafer-head,nylon-coated(4)
Black0.392Nm
(4kgf-cm)
Chapter9.RemovingorreplacingaFRU97
