ThinkPad Edge E530 - 1160 Speaker Assembly

7
7
7
StepScrew(quantity)Color
Torque
7
M2×5mm,wafer-head,nylon-coated(3)Silver
0.181Nm
(1.85kgf-cm)
8
9
Wheninstalling:Makesurethattheconnectorisattachedrmlytothesystemboard.
1160Speakerassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
•“1040Opticaldriveorblankbezel”onpage65
•“1120Keyboard”onpage76
•“1130Keyboardbezel”onpage80
Removalstepsofspeakerassembly
Forsomemodels:
86HardwareMaintenanceManual
