ThinkPad Edge E530 - 1020 Large Bottom Cover

Unlockthebatterylatch1.Holdthebatterylockleverintheunlockedposition,andremovethebattery
pack2.
2
2
1
Wheninstalling:Installthebatterypackintheslot.Makesurethatthebatterylatchisinthelockedposition.
1020Largebottomcover
Foraccess,removethisFRU:
•“1010Batterypack”onpage62
Removalstepsoflargebottomcover
Note:Loosenthescrews1.
2
1
1
1
Chapter9.RemovingorreplacingaFRU63
