ThinkPad Edge E530 - 1130 Keyboard Bezel

1130Keyboardbezel
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
•“1040Opticaldriveorblankbezel”onpage65
•“1120Keyboard”onpage76
Removalstepsofkeyboardbezel
1
1
1
1
1
1
1
1
1
1
1
2
2
2
Note:Yourmodelmightlookslightlydifferentfromtheillustrationabove.
StepScrew(quantity)Color
Torque
1
M2×8mm,wafer-head,nylon-coated(11)
Black0.181Nm
(1.85kgf-cm)
2
M2×3mm,wafer-head,nylon-coated(3)
Black0.181Nm
(1.85kgf-cm)
80HardwareMaintenanceManual
