1200
Optical
drive
sub
card
F
or
access,
remove
these
FRUs
in
or
der:
•
“1010
Battery
pack”
on
page
62
•
“1020
Large
bottom
cover”
on
page
63
•
“1040
Optical
drive
or
blank
bez
el”
on
page
65
•
“1120
Keyboard”
on
page
76
•
“1130
Keyboar
d
bezel”
on
page
80
Removal
steps
of
optical
drive
sub
card
1
2
When
installing:
Make
sure
that
the
connector
is
attached
rmly
to
the
system
boar
d.
3
4
Chapter
9
.
Removing
or
replacing
a
FRU
93
