Wheninstalling:Attachthelargebottomcoverasshowninthefollowingillustration.
1030Smallbottomcover
Foraccess,removethisFRU:
•“1010Batterypack”onpage62
Removalstepsofsmallbottomcover
Note:Loosenthescrew1.
2
1
Wheninstalling:Attachthesmallbottomcoverasshowninthefollowingillustration.
64HardwareMaintenanceManual
