ThinkPad Edge E530 - 1170 Power Button Sub Card; Color Torque Black 0.181 Nm (1.85 Kgf-CM)

1170Powerbuttonsubcard
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
•“1040Opticaldriveorblankbezel”onpage65
•“1120Keyboard”onpage76
•“1130Keyboardbezel”onpage80
Removalstepsofpowerbuttonsubcard
1
2
2
StepScrew(quantity)Color
Torque
1
M2×3mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
Chapter9.RemovingorreplacingaFRU89
