Forothermodels:
1
1
1
1
StepScrew(quantity)Color
Torque
1
M2×2mm,wafer-head,nylon-coated,bighead(4)
Black0.181Nm
(1.85kgf-cm)
2
2
Wheninstalling:Attachthespeakerassemblyandroutethecableasshowninthefollowinggure,and
makesurethatthespeakerconnectorisattachedrmly.
88HardwareMaintenanceManual
