ThinkPad Edge E530 - 2040 Wireless Antenna Assembly and LCD Rear Cover Assembly

RemovalstepsofLCDcables
1
2
1
1
2040WirelessantennaassemblyandLCDrearcoverassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
•“1030Smallbottomcover”onpage64
•“1040Opticaldriveorblankbezel”onpage65
•“1070PCIExpressMiniCardforwirelessLAN”onpage68
•“1080PCIExpressMiniCardforwirelessWANormSATAsolidstatedrive”onpage69
•“1120Keyboard”onpage76
•“1130Keyboardbezel”onpage80
•“1190RJ45subcard”onpage91
•“1210LCDunit”onpage94
•“2010LCDbezelassembly”onpage99
•“2020LCDpanelandhinges”onpage101
•“2030IntegratedcameraandLCDcables”onpage103
Chapter9.RemovingorreplacingaFRU105
