RemovalstepsofwirelessantennaassemblyandLCDrearcoverassembly
ReleasetheantennacablesfromthecableguidesontheLCDrearcoverassembly.
1
1
1
2
2
2
2
1
Note:YourmodelmightnothavethewirelessWANantennaassembly.
3
3
Note:YourmodelmightnothavethewirelessWANantennaassembly.
Cablerouting:Whenyouinstallthewirelessantennaassembly,routethecablesasshowninthefollowing
gures.Asyouroutethecables,makesurethattheyarenotsubjecttoanytension.Tensioncouldcausethe
cablestobedamagedbythecableguides,orawiretobebroken.
aWirelessLANAUXantenna(black)
bWirelessWANAUXantenna(blue)
cWirelessWANMAINantenna(red)
dWirelessLANMAINantenna(gray)
106HardwareMaintenanceManual
