ThinkPad Edge E530 - 2030 Integrated Camera and LCD Cables

Removalstepsofhinges
1
1
1
1
1
1
2
2
StepScrew(quantity)Color
Torque
1
M2×3mm,wafer-head,nylon-coated,smallhead(6)
Black0.181Nm
(1.85kgf-cm)
2030IntegratedcameraandLCDcables
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
•“1030Smallbottomcover”onpage64
•“1040Opticaldriveorblankbezel”onpage65
•“1070PCIExpressMiniCardforwirelessLAN”onpage68
•“1080PCIExpressMiniCardforwirelessWANormSATAsolidstatedrive”onpage69
•“1120Keyboard”onpage76
•“1130Keyboardbezel”onpage80
•“1190RJ45subcard”onpage91
•“1210LCDunit”onpage94
•“2010LCDbezelassembly”onpage99
•“2020LCDpanelandhinges”onpage101
