Removalstepsofharddiskdriveassembly
Note:Yourmodelmightlookslightlydifferentfromtheillustrationabove.
StepScrew(quantity)Color
Torque
1
M2×3mm,wafer-head,nylon-coated(2)
Black0.181Nm
(1.85kgf-cm)
Wheninstalling:Makesurethattheharddiskdriveisattachedrmly.
Chapter9.RemovingorreplacingaFRU67
