Removalstepsofkeyboard
1
1
Notes:
•Y ourmodelmightlookslightlydifferentfromtheillustrationabove.
•Thelocationofthescrewsthatsecurethekeyboardmightbedifferentfromtheillustrationabove.Referto
thewatermarksprintedonthecomputer.
Wheninstalling:Makesurethatthescrewsarefastenedandthekeyboardissecured.
StepScrew(quantity)Color
Torque
1
M2×8mm,wafer-head,nylon-coated(2)
Black0.181Nm
(1.85kgf-cm)
2
2
Note:Yourcomputerkeyboardmightlookdifferentfromtheillustrationabove.
