Chapter7.Locations
Thischapterintroducesthelocationsofthecomputerhardwarecomponents.
Locatingcomputercontrols,connectors,andindicators
Thistopicintroducesthelocationsofthecomputercontrols,connectors,andindicators.
Frontview
1
1
2
8
9
10
11
13
14
15
16
3
4
5
6
7
12
1Built-inmicrophones9MiniDisplayPortconnector
2Integratedcamera
10USB3.0connector
3Windowsbutton11Fanlouvers
4Ambientlightsensor
12Systemstatusindicator
5Volumecontrolbuttons13Touchpad
6Screenrotationbutton
14TrackPointbuttons
7Powerbutton15TrackPointpointingstick
8acpowerconnector
16UltraNav
®
pointingdevice
©CopyrightLenovo2012,2013
