ThinkPad S230u - Battery Pack Replacement

•“1020Keyboard”onpage62
RemovalstepsofPCIExpressMiniCardforwirelessLAN
Instep1,unplugtheconnectorsbyusingtheremovaltoolantennaRFconnectororpicktheconnectors
withyourngersandgentlyunplugtheminthedirectionofthearrows.
1
1
2
StepScrew(quantity)Color
Torque
2
M2×3mm,wafer-head,nylon-coated(1)Silver
0.181Nm
(1.85kgf-cm)
3
Wheninstalling:Plugthegraycableintothemainconnector,andtheblackcableintotheauxiliary
connector.
1040PCIExpressMiniCardforwirelessWANormSATAsolid-statedrive
Foraccess,removethisFRU:
Chapter9.RemovingorreplacingaFRU65
