StepScrew(quantity)Color
Torque
1
M3×3mm,at-head,nylon-coated(4)Silver
0.3+
0.05Nm
(4.00kgf-cm)
2
1020Keyboard
Removalstepsofkeyboard
1
1
StepScrew(quantity)Color
Torque
1
M2×5mm,wafer-head,nylon-coated(2)
Black0.181Nm
(1.85kgf-cm)
Pressthekeyboardinthedirectionshownbythearrows2untiltherearedgeofthekeyboardisdetached
fromthekeyboardbezel.
62HardwareMaintenanceManual
