ThinkPad S230u - Chapter 9. Removing or Replacing a Fru

StepScrew(quantity)Color
Torque
3
M2.5×4mm,wafer-head,nylon-coated(2)Silver
0.181Nm
(1.85kgf-cm)
Instep4,detachthewirelessantennas,andreleasethecablesfromthecableguides.
4
4
4
4
4
4
Wheninstalling:
•Ensurethatyouattachtheconnectorsrmlyinthefollowingorder:
1WirelessWANauxiliaryconnector
2WirelessLANmainconnector
3WirelessLANauxiliaryconnector
4WirelessWANmainconnector
5LCDcableassembly
6Powercableassembly
•Whenyouroutethecables,ensurethattheyarenotsubjecttoanytension.Tensioncouldcausethe
cablestobedamagedbythecableguides,orawiretobebroken.
Chapter9.RemovingorreplacingaFRU77
