ThinkPad S230u - 2060 Wireless Antenna Assembly, LCD Cable Assembly, Power Cable Assembly, and LCD Rear Cover Assembly

1
2
3
4
5
6
1LCDcableassembly
4WirelessLANmainantenna
2WirelessLANauxiliaryantenna5WirelessWANauxiliaryantenna
3WirelessWANmainantenna6Powercableassembly
4.Aftertheinstallation,ensurethatyoucanseetherubberbwhentheLCDisopen.Otherwise,reinstall
thehingeandensurethatyouinstalledtherubbercorrectly.
b
2060Wirelessantennaassembly,LCDcableassembly,powercable
assembly,andLCDrearcoverassembly
Foraccess,removetheseFRUsinorder:
•“1010Harddiskdriveorsolid-statedrive”onpage60
•“1020Keyboard”onpage62
•“1050Keyboardbezel,backupbattery,andspeakerassembly”onpage68
•“1060Batterypack”onpage71
•“1090LCDunit”onpage76
88HardwareMaintenanceManual
