ThinkPad S230u - 1050 Keyboard Bezel, Backup Battery, and Speaker Assembly

StepScrew(quantity)Color
Torque
1
M2×3mm,wafer-head,nylon-coated(1)Silver
0.181Nm
(1.85kgf-cm)
2
1050Keyboardbezel,backupbattery,andspeakerassembly
Foraccess,removetheseFRUsinorder:
•“1010Harddiskdriveorsolid-statedrive”onpage60
•“1020Keyboard”onpage62
Removalstepsofkeyboardbezel
1
2
2
2
2
2
2
2
2
StepScrewcapScrew(quantity)Color
Torque
1
M2×5mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
2
M2×5mm,wafer-head,nylon-coated(8)
Black0.181Nm
(1.85kgf-cm)
68HardwareMaintenanceManual
