ThinkPad S230u - Rear View; Bottom View; Locating Frus and Crus

Rearview
1
2
3
4
5
6
7
8
1Systemstatusindicator
5Ethernetconnector
2Comboaudiojack
6Mediacardreaderslot
3USB3.0connector7SIMcardslot
4HDMIconnector
8Securitykeyhole
Bottomview
3
1
2
1Harddiskdriveorsolid-statedrive3Batterypack
2Emergencyresethole
LocatingFRUsandCRUs
Thistopicintroducesthefollowingserviceparts:
•“MajorFRUsandCRUs”onpage50
•“LCDFRUs”onpage52
48HardwareMaintenanceManual
