ThinkPad S230u - 2010 Button Bezel; 2020 LCD Panel

2010Buttonbezel
Removalstepsofbuttonbezel
1
1
2
2
StepScrewcapScrew(quantity)Color
Torque
1
M2×5mm,wafer-head,nylon-coated(2)Silver
0.181Nm
(1.85kgf-cm)
2
M2.5×4mm,wafer-head,nylon-coated(2)Silver
0.181Nm
(1.85kgf-cm)
Liftthebuttonbezelslightlyasshownbythearrow3.Thendetachthelatches4inascendingalphabetical
orderasillustrated.
3
4a
4b
4c
4d
4e
4f
4h
4g
Wheninstalling:Ensurethatallthelatchesareattachedrmlyandthebuttonbezelissecuredwithscrews.
2020LCDpanel
Foraccess,removethisFRU:
•“2010Buttonbezel”onpage83
Chapter9.RemovingorreplacingaFRU83
