Removalstepsofintegratedcamera
2
1
Wheninstalling:Ensurethattheconnectorisattachedrmly.
2050Hinge
Foraccess,removetheseFRUsinorder:
•“1010Harddiskdriveorsolid-statedrive”onpage60
•“1020Keyboard”onpage62
•“1050Keyboardbezel,backupbattery,andspeakerassembly”onpage68
•“1060Batterypack”onpage71
•“1090LCDunit”onpage76
•“2010Buttonbezel”onpage83
Removalstepsofhinge
1
1
2
StepScrew(quantity)Color
Torque
1
M2.5×4mm,wafer-head,nylon-coated(2)Silver
0.181Nm
(1.85kgf-cm)
86HardwareMaintenanceManual
