•“2010Buttonbezel”onpage83
•“2020LCDpanel”onpage83
•“2030Buttonboard”onpage84
•“2040Integratedcamera”onpage85
•“2050Hinge”onpage86
Removalstepsofwirelessantennaassembly
Releasethewirelessantennacablesfromthecableguides.
2
2
2 2
2 2 2
2
2
1 1 1
1
Wheninstalling:Asyouroutethecables,ensurethattheyarenotsubjecttoanytension.Tensioncould
causethecablestobedamagedbythecableguides,orawiretobebroken.
