© 2013 Thorlabs GmbH508
DCx Cameras
Parameter
Description
Value range
Example
brightness control
Brightness Hysteresis
Hysteresis value for auto
exposure and gain (see
IS_SET_AUTO_HYSTERESIS
)
0…10
2
Brightness Skip Frames
Number of images that will be
not analyzed for the control
(see
IS_SET_AUTO_SKIPFRAMES
)
0…1000
4
Auto WB control
Enable white balance control
0, 1
0
Auto WB type
White balance mode
Auto WB RGB color mode
Color space of white balance
(only active, if the mode "Auto
(Kelvin)" is set)
Auto WB offsetR
Red offset for white balance
control
0...100
0
Auto WB offsetB
Blue offset for white balance
control
0...100
0
Auto WB gainMin
Minimum gain for white balance
control
0 <= gainMin <= gainMax <=
100
0
Auto WB gainMax
Maximum gain for white balance
control
0 <= gainMin <= gainMax <=
100
100
Auto WB speed
White balance control speed
0...100
50
Auto WB Aoi Left
X start point of reference AOI for
white balance control
0...(max. width
*1
-Aoi Width)
0
Auto WB Aoi Top
Y start point of reference AOI for
white balance control
0...(max. height
*1
-Aoi Height)
0
Auto WB Aoi Width
Width of reference AOI for white
balance control
Sensor-dependent
*1
2560
Auto WB Aoi Height
Height of reference AOI for
white balance control
Sensor-dependent
*1
1920
Auto WB Once
Carry out white balance control
once
0, 1
0
Auto WB Hysteresis
Hysteresis value for auto white
balance (see
IS_SET_AUTO_WB_HYSTERES
IS )
0…10
2
Auto WB Skip Frames
Number of images that will not
be analyzed for control (see
IS_SET_AUTO_WB_SKIPFRAM
ES )
0…1000
4
[Trigger and Flash]
Sets the digital inputs/outputs
Trigger mode
Trigger mode
Trigger timeout
Timeout value for triggered
image capture in 10 ms steps
Trigger delay
Delay of triggered image
capture in µs
Sensor-dependent
*1
15
Trigger debounce mode
Not supported by DCx cameras
Trigger debounce delay
time
Not supported by DCx cameras
10
Trigger burst size
Not supported by DCx cameras
Flash strobe
Activate flash output
0...6
*2
0
306
305
307
307
