© 2013 Thorlabs GmbH162
DCx Cameras
hCam
Camera handle
IS_AOI_SEQUENCE_GET_ENABLE
Returns the bitmask (only DCC1240x/DCC3240x camera models)
Sample 3 for sequence AOI mode
pParam
Pointer to a function parameter, whose function depends on nCommand.
nSizeOfParam
Size (in bytes) of the memory area to which pParam refers.
Contents of the IS_RECT structure
INT
s32X
X position of the AOI
INT
s32Y
Y position of the AOI
INT
s32Width
Width of the AOI
INT
s32Height
Height of the AOI
Contents of the IS_POINT_2D structure
INT
s32X
X position of the AOI
INT
s32Y
Y position of the AOI
Contents of the IS_SIZE_2D structure
INT
s32Width
Width of the AOI
INT
s32Height
Height of the AOI
Content of the AOI_SEQUENCE_PARAMS structure
INT
s32AOIIndex
Index of the AOI
INT
s32NumberOfCycleRepetitions
Number of readout cycles
INT
s32X
X position of the AOI
INT
x32Y
Y position of the AOI
Double
dblExposure
Exposure
INT
s32Gain
Gain
INT
s32BinningMode
Binning mode (not supported in version 4.20)
INT
s32SubsamplingMode
Subsampling mode (not supported in version 4.20)
INT
s32DetachImageParameters
0 = every change of the exposure time and the master
gain is copied from AOI 1 to the additional AOIs
(default).
As a change of AOI 1 also reset the exposure time,
this change is also transferred to AOI 2, 3 and 4.
1 = a change of exposure time, gain or position of AOI
1 does not affect the parameters of AOI 2, 3 and 4.
Double
dblScalerFactor
Scaling factor (not supported in version 4.20)
BYTE
byReserved[64]
Reserved
