OPERATING MANUAL TW63 PRODUCT DESCRIPTION
ThyssenKrupp Aufzugswerke GmbH
Traction sheave:
The one-part traction sheaves are fastened overhung on the drive shaft
by using a cone (1:15) and a mounting plate including 3 screws (M16-8.8
microencapsulated with locking washer).
Designation Unit Technical data
Machine version
Standard
SA9 - SA9
Diameter - DT mm 450 510 590 520 675
Rim width - B mm 132 110 96
Max. number of grooves -
z x d
8 x 8 8 x 8
5 x 13
6 x 8
7 x 10/11 7 x 10/11 5 x 10/11
6 x 12 4 x 12
Groove type Seat / vee groove
Vee groove angle °
Depends on project specs
1)
Vee groove K40
2)
Weight kg 50 60 70 50 70
Material Specially alloyed EN-GJL 250
Version in accordance with a factory standard 60 300 50 00 0 with hardened groove flanks
(min. 50 HRc)
2)
Standard version
TW63_30301_ENG
Table 2.2.1
