OPERATING MANUAL TW63 PRODUCT DESCRIPTION
ThyssenKrupp Aufzugswerke GmbH
2. Product description
2.1 Description
1
Actual-value sensor 9 Rope guard
2
Handwinding wheel / flywheel rim 10 Machine base frame (optional)
3
Forced ventilation (optional) 11 Name plate
4
Motor 12 Gear housing
5
Armature base plate 13 Rope guard carrier
6
Brake shoe 14 Brake monitoring switch
7
Traction sheave 15 Motor terminal box
8
Disc on the traction sheave shaft 16 Brake magnet
Versions:
The following version of the machine can be chosen depending on customer
needs: gear reduction, traction sheave version, motor version, motor
arrangement (vertical / horizontal), encoder version
1
2
3
4
5
6
7
8
9
15
14
13
12
11
9
10
Fig. 2.1
Version TW63 V
(vertical motor arrangement)
10
09-2012
