OPERATING MANUAL TW63 TECHNOLOGY
ThyssenKrupp Aufzugswerke GmbH
3.2 Dimensions of machine
3.2.1 Version with motor type A4 / vertical motor position
1 Air guidance, motor 2 Centre of gravity
Fig. 3.2.1
09-2012
