Page #14 background imageLoading...
Page #14 background image
OPERATING MANUAL TW63 TECHNOLOGY
ThyssenKrupp Aufzugswerke GmbH
3. Technology
3.1 Technical data
Permitted load of the traction sheave shaft:
for standard version max. 43 kN
for SA 9 (extended wheel shaft) max. 41 kN
Axle distance: 155 mm
Brake magnet connection:
In the case of the TW63 machine, the
Connection values magnetic clamp: two magnets are connected in succession.
Rated voltage: 50 V
Power supply
Rated current: 1.1 A for field forcing device: 200 V
Type of protection: IP65 for retentive voltage: 100 V
Magnetic clamp nominal force: 2* 2500 N
Max. braking torque: approx. 2* 90 Nm
Brake disc diameter: 200 mm
Weight:
Standard version of motor in A4 design
Gear drive (without motor and traction sheave) 250 kg
Gear drive SA 9 (without motor and traction sheave) 290 kg
Gear drive (with motor and traction sheave) approx. 370 kg
Gear drive SA 9 (with motor and traction sheave) approx. 410 kg
Traction sheave according to order 450 - 675 mm dia. approx. 50 - 70 kg
09-2012
