OPERATING MANUAL TW63 COMMISSIONING
ThyssenKrupp Aufzugswerke GmbH
6. Commissioning
Before commissioning the machine, the following points should be checked
and carried out:
• Safety, auxiliary and installation tools removed from the danger zone
• Check the setup of the machine, base frame, pedestal and rope departure
• Oil drain pipe mounted and closed off with cap
• Gear oil level checked
• Mounting of the machine and base frame checked
• With a side or oblique rope departure, gear box casing secured against
moving with steady plates and set screws
• Bolts tightened and secured with the prescribed torque (see table
'Tightening torques', 9.1)
• Brake block stroke and setting checked
• With SA3, setting and function of the brake test switch checked
• Brake test carried out with one brake block in each case
• Function of handbrake release checked
• Rope guard fitted and distance to traction sheave set
• Power connections and earthing of motor, forced ventilation and brake
magnet connected and secured
• Direction arrow (Up / Down) attached above traction sheave and clearly
visible on the motor near the handwinding wheel according to the direction
of travel
Note: If the traction sheave and rope pulley are delivered separately, they
are to be mounted properly.
If the machine was dismantled due to weight, transport or space, removed
parts are to be reassembled to their original state and the mounting parts
tightened with the corresponding tightening torque (see table 'Tightening
torques', 9.1).
For assembly, use only original construction and mounting parts from
Thy
ssenKrupp Aufzugswerke GmbH, as otherwise no warranty can be
provided.
